The door adopts a horizontally split double-sash structure with independent opening for upper and lower panels, suitable for main barn aisles, partition barriers and breeding stables. It drastically reduces the frequency of fully opening the door and lowers horse stress. The upper half is equipped with a classic V-Yoke diagonal ventilation grille. Different from dense traditional vertical bars, it balances ventilation, visual aesthetics and horse safety.
The stall partition features a soft V-shaped grille, which removes the prison-like oppressive feel of traditional dense vertical bars to calm horses and reduce restless behaviours such as kicking doors. Wider gaps in the V-grille improve ventilation, quickly expelling hot humid air and ammonia to protect equine respiratory health, ideal for tropical regions and enclosed barns. The staggered diagonal V-bars limit horses from extending their heads outward, preventing biting and fighting between adjacent horses and safeguarding broodmares, foals and skittish horses.
Solid lower panels block disturbances from aisle traffic and shifting light, creating private spaces for horses to rest, foal and recover. Designed with a split small sash and silent hinges, only the upper sash needs opening for feeding, inspection or treatment, avoiding sudden wind and bright light that may spook horses. Burr-free panels including high-density compressed bamboo and HDPE sheets prevent cuts. HDPE sheets resist urine and disinfectant corrosion, are easy to hose clean and suppress bacteria, lowering risks of equine skin allergies.
Horse stall streamlines daily stable management and reduces labor costs. Feeding and health checks can be done just by opening the upper sash without fully taking horses out, cutting escape risks. Its transparent V-grille allows continuous horse monitoring and stops cross-stall disturbance, removing the need for round-the-clock stall watch.
With classic European vintage V-Yoke diagonal grilles, it improves barn aesthetics, unlike plain cheap vertical railings. Arched or flat door frames and multi-color powder coating suit luxury private stables, riding schools and breeding farms. Two infill options are available: high-density compressed bamboo panels with strong anti-chew properties, and maintenance-free HDPE panels ideal for coastal or humid regions.
Separate locks on upper and lower sashes prevent horses from pushing doors open. Made of thickened hot-dip galvanized Q235 steel, the sturdy 50×50 square tube frame resists kicks and rust, offering over 10 years of outdoor service.
Two universal Dutch stable door sizes complying with global equine industry norms: 1200mm(W) × 2200mm(H) / 1200mm(W) × 2400mm(H)
1.2m (4ft) standard width fits all horse breeds from ponies to warmbloods and allows easy handler passage for leading horses.
· 1200×2200mm: Cost-effective standard model for private European stables and riding schools, suited for regular sport horses.
· 1200×2400mm: Raised height model preferred by premium stables in North America, Middle East and Central America, offering larger upper ventilation area and classic vintage barn aesthetics.
Custom width & height sizes are fully supported.
Fully tailored for equine projects across Europe, North America, the Middle East and Central America, compatible with both temporary portable stables and permanent fixed barns.
Size & opening type: Custom width & height available; space-saving sliding version for narrow aisles as an alternative to hinged doors.
Powder coating colors: Matte black, navy blue, scarlet red, forest green, pure white, plus custom matched colors upon client request.
Upper sash ventilation styles: Straight vertical grille, flagship V-Yoke diagonal grille, large curved arch "smile" grille, 8mm thick transparent PC viewing window, fully insulated solid closed panel.
Door frame & decoration: Minimalist flat top frame or vintage arched top frame; optional X-shaped bamboo wood trim and custom carved patterns on panels.
Hardware upgrades: Standard hot-dip galvanized hinges; premium silent buffer hinges to eliminate slamming noise; full 304 stainless steel hardware upgrade for high salt coastal regions.
Three optional infill panels (New HDPE premium plastic panel included):
High-density compressed bamboo solid panel: Available in 20/24/28/32mm thickness, anti-chew, impact resistant, naturally mildew and moisture proof.
HDPE high-density polyethylene plastic panel (new option): Zero maintenance, non-water-absorbent, resistant to horse urine & disinfectant chemicals, no mildew, cracking or wood splinters. The all-weather choice for tropical and coastal facilities, stable under extreme heat and humidity without warping or expansion. Uniform integrated coloring that won’t fade or chalk under sunlight, available in 20/24/28/32mm thickness matching bamboo panels.
Solid timber panel: Custom vintage farm style alternative.
Custom brand nameplates: Stainless steel or aluminum rust-proof plates available, with laser engraving, embossing or silk printing of farm names, brand LOGOs, slogans or stall numbers. UV and water resistant for long indoor & outdoor use, installed with hidden fasteners for clean door surfaces without damage.
Indoor and outdoor universal, ideal for private stables, commercial riding training yards and breeding farms worldwide.
Standard single stall front door: Classic independent stable door with transparent non-oppressive V-grille. Staff only open upper sash for feeding and inspection while keeping horses fully separated and safe.
Outdoor open-air stable / pasture fence gate: Heavy Q235 steel with full hot-dip galvanization, rain, humidity, high temperature and sandstorm resistant for long-term outdoor service.
Breeding farm isolation stalls (Mare & foal): Separate top & bottom locks stop foals pushing doors open; solid bamboo or HDPE panels create quiet private zones to calm horses; V-grilles prevent foals from fighting each other, and silent hinges avoid sudden noise startling pregnant mares and newborn foals.
Commercial riding schools & sport horse training centers: Fully welded thick steel frames withstand frequent door opening and horse kicking. Flagship V-grille design delivers high-end uniform venue styling across multiple stalls to boost institutional brand recognition with custom engraved nameplates.
Vintage luxury private stables & pastoral farms: Arched frames paired with V-diagonal grilles create classic European equine aesthetics, matching timber or metal barn facades. Custom engraved nameplates highlight exclusive high-end positioning.
Veterinary rehabilitation & therapy stables: Optional transparent viewing windows or V-grilles allow horse observation without fully opening doors; silent hardware maintains quiet resting environments, and solid lower panels reduce external disturbance for injured horses.
Indoor round pens & barn aisle partition doors: Standard dimensions fit side entryways and zone separation, with V-grilles balancing ventilation and horse safety.
Main material: Heavy-gauge Q235 carbon steel.
All door parts are fully cut and 100% full welded first, then processed with complete post-fabrication hot-dip galvanization.
This is the most reliable anti-rust method for stable doors, covering all welds, edges and holes completely without bare steel exposure.
Material specifications:
Q235 heavy carbon steel as primary frame
Angle iron: 75×75×5mm
Square tube: 50×50×2.5mm
100% fully integrated welded structure delivers extreme rigidity, resisting heavy horse impact without deformation or fracture.
After galvanization, durable outdoor powder coating is applied for extra protection. The finish is UV-resistant, scratch-resistant, and able to withstand regular outdoor weather changes without peeling or fading.
High-density monolithic compressed bamboo solid panel Waterproof, moisture resistant, anti-chew and impact resistant, lasting many years without cracking or breakage under regular stable conditions. Thickness options: 20/24/28/32mm.
HDPE high-density polyethylene premium plastic panel (new option) Zero-maintenance premium infill sheet with near-zero water absorption rate. Resistant to horse urine, disinfectants and acid/alkaline chemicals, smooth surfaces that hose clean instantly to inhibit mold and bacterial growth. Free of wood splinters, resistant to horse chewing, stable under extreme hot/cold temperatures without expansion or warping. No annual oiling or repainting required, with a long service life, perfect for rainy, tropical and coastal stables. Available in 20/24/28/32mm thickness.
Solid timber panel: Custom vintage farm alternative only.
Independent locking hardware for upper and lower sashes to eliminate accidental horse escape risks. All locks are fully hot-dip galvanized for corrosion resistance:
Spring plunger latch
Thumb push lock
Standard stable deadbolt lock
Lock sample photos available upon client request for selection.
Two universal hinge options for all stable environments:
Standard model: 4 pieces of thick Q235 hot-dip galvanized hinges, high load bearing, stable and deformation resistant under frequent opening and horse impact.
Premium silent buffer hinge: Custom silent damping design for soft, quiet door operation to avoid startling horses, ideal for breeding farms, vet rehabilitation yards and luxury private stables.
Full 304 stainless steel hinge upgrade available for high-corrosion locations. Sliding door versions come with dedicated silent sliding rails with no hinges to save aisle space.
Exclusive personalized customization for global equine clients:
Materials: 304 stainless steel plate, rust-proof aluminum alloy plate
Techniques: Laser engraving, embossing, color silk screen printing
Custom content: Farm LOGO, enterprise name, stall numbers, personalized slogans
Features: Waterproof, rust-proof, UV resistant
Installation: Hidden fastener mounting for neat appearance
Two door frame top styles: Minimalist flat top (modern contemporary) or vintage curved arch top (European classic).
Upper sash optional styles: Fully solid closed panel, straight vertical grille, flagship V-Yoke diagonal grille, curved "smile" arch grille, transparent PC viewing window.
Standard powder coat colors: Matte black, dark grey, navy blue; custom special color matching available upon request.
Standard sizes: 1200W×2200H / 1200W×2400H, fully customizable to non-standard dimensions.
Complete production drawings + bilingual step-by-step installation manual provided after order confirmation, alongside a full set of installation fasteners and accessories.
Most competitors use pre-galvanized tubes, which lose zinc coating after cutting and welding, causing weld rust within 1–3 years outdoors.
Our production process is completely different: 100% full welding first → full hot-dip galvanization after fabrication
All weld seams, cutting edges and hole positions are fully covered with zinc layer. No bare steel exposed.
Our doors guarantee more than 10 years rust-free service for outdoor barn use, far more durable than ordinary pre-galvanized stable doors.
Many competitors fake tube thickness by double-sided labeling.
We use genuine single-layer thick Q235 steel:
Load-bearing angle iron: 75×75×5mm real thickness
Square frame tube: 50×50×2.5mm real thickness
Full welded rigid structure stays stable and deformation-free under strong horse kicking.
Most split doors on the market use dense vertical bars which look depressing and easily make horses nervous.
Our exclusive V-type diagonal grille provides softer visual effect, better air circulation and effective anti-fight protection between adjacent horses. It improves horse mood and upgrades the overall barn appearance.
We provide two practical infill solutions: durable compressed bamboo and zero-maintenance HDPE panel, suitable for all climate conditions.
Ordinary cheap doors use one shared lock for upper and lower sashes, easy for horses to push open.
Our separate upper & bottom locking system greatly reduces escape risk. All galvanized hardware is sturdy and durable for long-term stable daily use.
All doors are carefully welded with smooth burr-free surfaces to prevent horse scratches. Powder coating is uniform and durable for outdoor long-term use.
We provide accurate production drawings, bilingual installation guides and full installation accessories for easy and fast on-site assembly.
Our Dutch stable doors adopt real thick Q235 steel, full welded structure and professional post-weld hot-dip galvanization technology to ensure stable quality and long anti-rust lifespan over 10 years.
With exclusive horse-friendly V-grille design, double independent locking system, optional zero-maintenance HDPE panels and silent hardware upgrades, our doors balance safety, horse comfort, easy management and high-end appearance.
Widely exported to Europe, North America, Middle East and Central America, it is a reliable choice for commercial riding schools, breeding farms and private luxury stables.
Q: What is your anti-rust treatment? How long can it last outdoors?
A: We adopt full welded fabrication first, then complete hot-dip galvanization. All welds and edges are fully protected. Our doors can keep rust-free for more than 10 years under normal outdoor barn conditions.
Q: What are the steel specifications? Can it resist horse kicking?
A: Thick Q235 carbon steel structure with 75×75×5mm angle iron and 50×50×2.5mm square tube. 100% full welded structure is strong enough to resist daily horse kicking without deformation.
Q: What are the advantages of V-Yoke grille over vertical bars?
A:
1. Softer visual effect without prison-style depression, calming horses effectively.
2. Bigger ventilation space to release heat, humidity and ammonia, protecting horse respiratory health.
3. Diagonal bars limit horse head stretching and avoid biting or fighting between adjacent stalls.
4. Classic European style improves the overall barn aesthetic.
Q: What panel options do you have? What is the advantage of HDPE?
A: Three options:
1. High-density compressed bamboo panel: anti-kick, durable for normal use.
2. HDPE plastic panel: zero maintenance, waterproof, anti-mold, anti-urine, no wood splinters, long service life for coastal & tropical areas.
3. Solid timber panel for vintage style.
Q: Does the upper and lower door share one lock? Can horses open it?
A: No. We use separate independent locks for upper and lower sashes to prevent horses from pushing the door open accidentally.
Q: Can I customize colors, sizes and door styles?
A: Yes. We support custom sizes, flat/arched door frames, multiple upper grille styles and customized powder coating colors.
Q: Do you provide installation drawings and accessories?
A: Yes. We provide full production drawings, bilingual installation manuals and complete installation hardware sets.
Q: Is the door suitable for export and coastal areas?
A: Yes. Our full hot-dip galvanized structure offers excellent anti-rust performance for outdoor, humid and coastal environments, widely exported to global equine projects.
Q: What hardware do you supply? Can I add custom logo plates?
A: Standard hot-dip galvanized thick hinges included. Silent hinges and 304 stainless steel hardware are optional. Custom laser engraved nameplates are available for brand upgrading.
